IMAX B6 80W RC Lipo NiMh Battery Balance Charger/Discharger 1-6 Cells with LCD Screen Digital &INSTRUCTION MANUAL | Электроника - 74000016983784

Характеристики

IMAX B6 80W RC Lipo NiMh Battery Balance Charger/Discharger 1-6 Cells with LCD Screen Digital

The multifunction battery charger is a microprocessor-controlled quick charger for NiCd, NiMH, lipo, LiIon, LiFePo and lead acid rechargeable batteries. A balancer is integrated to balance lithium batteries. Features - Charging function: max. charging current 5 A - Discharge function: max. discharge current 1 A - Balancer current: max. 300 mA/cell - For 1 to 15 cells NiCd/NiMH - For 1 to 6 cells LiIon, LiPo, LiFePo - Lead batteries: 2 to 20 V - Supply voltage: 11 to 18 V DC - Fast and normal (storage) charging, cycles, depending on battery type - Automatic charging shut-off, safety timer - Battery temperature monitoring (external sensor not included) - Battery parameter memory for up to five rechargeable batteries Technical data: - Input voltage: 11 to 18 V DC - Power: charging: 50 W, discharging 5 W - Charging current: 0.1 to 5 A - Discharge current: 0.1 to 1 A - Balancer current: 300 mA/cell - Number of lithium battery cells: 1 to 6 cells - Number of NiMH/NiCd battery cells: 1 to 15 cells - Number of lead acid battery cells: 1 to 10 (2 to 20 V) - Special features: integrated balancer, - Reserved interface for temperature sensor (need to prepare by yourself, this sensor not included in the sales package) - Dimensions (W x H x D): 133 x 87 x 33 mm - Weight: 277 g
